Accessories
7
-
17
Figure
7-12
Attaching the CAM
T
o remove, squeeze the latch grips and pull the CAM from the MC92N0-G.
Setup
Figure
7-13
CAM Power Connection
NOTE
Remove the CAM from the bottom of the MC92N0-G before using a cradle for charging and communication.
OR
V
ehicle Power
Supply
AC Power
Supply
Into Cigarette
Lighter
168
170
