User’s Guide Kona cutting plotter
Through cutting
AP-75380 - Revision 1.2 143
7
Step 6: Press the test key to verify the quality of the through cutting settings.
Step 7: The following pattern will be cut.
Step 8: Check if it is easy to push out the cut patterns.
If not, try to increase the force and knife depth
Step 9: Be sure to perform a sheet-off after the test because the pushed-out squares/circles
will uncover the paper sensor which could lead to an error.
Refer to Toolswap settings on page140
to know how to use the single and multi-tool
possibility throughcutting.
