3.6.3 Loading sheet media
Configuration to start from
 The pressure rollers are raised.
 The rear media collection bag is open and empty.
 Open the front media collection bag when the cutting job is smaller than 4m.
 Close the front media collection bag when the cutting job is larger than 4m.
 Remove the media support rollers
Media loading procedure
Step 1: Guide the media under the pressure rollers at the front of the cutter.
Note
 In case of working with curled media, refer to Loading curled media on page65.
