4.2.4 Settings 3/4
Epos
Epos Alignment
This test will fine-tune the position of the cutting knife compared to the EPOS laser. This test
can be done manually and automatically. It is recommended however, to let the Kona adjust
the values automatically.
Step 1: Install and set a knife.
Refer to Installing tools on page37
Step 2: Install a dark (black) vinyl. Check with the EPOS readout function if it is dark enough
as described in EPOS read on page120
.
Note
 It is advised to perform this test for each completely new cutting knife.
