User’s Guide Kona cutting plotter
Operation panel
AP-75380 - Revision 1.2 79
4
Offset
One of the most important factors to obtain good quality, but unfortunately also one of the
factors that is easily forgotten, is the offset. As you can see in the figure below, the knife offset
(1) is the distance between the knife centre and the knife tip.
Accurate measurement of the offset to be used is very difficult and requires specialized
equipment. You should therefore adjust the offset (1) by checking real cutting results on the
media you will use. Mutoh helps you doing this by way of a semi-automatic offset adjustment
routine, which is integrated into your cutter.
Please follow the procedure below to perform this test:
Step 1: Press the following buttons in order:
Settings
Offset
Test
