NAVI F-52 - Page 184

Chapter 13 ANALOG OUTPUT
13.2 Analog Output Range
F-52, 53, 54, 55 171
COND
In S/cm
0.200 to 1.999 S/cm 1000 to 1500 mV Measurement value ×
250+1000
20.0 to 199.9 mS/cm 500 to 1000 mV Measurement value ×
2500+500
2.00 to 19.99 mS/cm 0 to 500 mV Measurement value × 2.5 ×
10
4
0.200 to 1.999 mS/cm -500 to 0 mV Measurement value × 2.5 ×
10
5
- 500
20.0 to 199.9(*3)
μS/cm
-1000 to -500 mV Measurement value × 2.5 ×
10
6
- 1000
2.00 to 19.99(*4)
μS/cm
-1500 to -1000 mV Measurement value × 2.5 ×
10
7
- 1500
0.000 to 1.999
μS/cm
-2000 to -1500 mV Measurement value × 2.5 ×
10
8
- 2000
Measured
object
Measured value Unit Output Conversion method
