Chapter 14 PRINTER
14.4 Sample Printout
178 HORIBA
● ION Measurement mode
● COND Measurement mode
Operator name: max. 12 letters
Temperature compensation
setting
At Manual mode: MTC
At Auto mode: ATC
MFG: max. 7 letters
ID#: max. 12 letters
Lot: max. 7 letters
Electrode model:max.9
EXACT printout
Electrode status:
with Calibration, “OK”
Sensitivity display
Standard solution value is dis-
played
No calibration/1-point calibration:
None
2-point calibration: 1st item
3-point calibration: 2nd item
4-point calibration: 3rd item
5-point calibration: 4th item
When the data in the one con-
firmed with AutoHold, “Stable” is
shown.
Nothing is displayed for the instan-
taneous value measurement.
Std.solution and potential:
● Up to 5-point CAL
BRIEF printout
Unit:
g/L, mg/L, μg/L, moll/L, mmol/L, μmol/L
Operator name: max. 12 letter
Temperature compensation
setting
At Manual mode: MTC
At Auto mode: ATC
MFG: max. 7 letters
ID#: max. 12 letters
Lot: max. 7 letters
Electrode model:max.9
EXACT printout
Cell constant
Unit: m
-1
, cm
-1
Temp. coefficient
0 to 9.99%/ ℃
OFF
PURE WATER
When the data in the one con-
firmed with AutoHold, “Stable” is
shown.
Nothing is displayed for the instan-
taneous value measurement.
DIsplayed only with CAL data
BRIEF printout
Unit:
S/m, mS/m, μS/m, S/cm, mS/cm, μS/cm
