Notifier AFP-200 Installation Manual

Annunciators Annunciator Capacity
142 AFP-200 PN 15511:H2 10/14/2002
ACS Point no. I/O Red LED Yellow LED Yellow LED with UDACT Switch Comments
1 Input System Alarm
System Trouble
1
System Trouble
1
Acknowledge
See Note 1
2 Output Not used Signals Silenced Signals Silenced Signal Silence
3 Output Not used Not used Program Mode System Reset
4 Output Not used Not used Supervisory Drill
5 Input Not used Supervisory Bell Trouble Not used Panel Supervisory LED on
6 Input Not used Pre-Alarm Pre-Alarm/Maint. Alert Not used Trouble
7 Input Not used Panel trouble Low Battery Not used Trouble
8 Input Not used AC Fail AC Fail Not used Battery/Earth Trouble
9 Input Z1 Active Z1 Trouble Not used
10 Input Z2 Active Z2 Trouble Not used
11 Input Z3 Active Z3 Trouble Not used
12 Input Z4 Active Z4 Trouble Not used
13 Input Z5 Active Z5 Trouble Not used
14 Input Z6 Active Z6 Trouble Not used
15 Input Z7 Active Z7 Trouble Not used
16 Input Z8 Active Z8 Trouble Not used
17 Input Z9 Active Z9 Trouble Not used
18 Input Z10 Active Z10 Trouble Not used
19 Input Z11 Active Z11 Trouble Not used
20 Input Z12 Active Z12 Trouble Not used
21 Input Z13 Active Z13 Trouble Not used
22 Input Z14 Active Z14 Trouble Not used
23 Input Z15 Active Z15 Trouble Not used
24 Input Z16 Active Z16 Trouble Not used
25 Input Z17 Active Z17 Trouble Not used
26 Input Z18 Active Z18 Trouble Not used
27 Input Z19 Active Z19 Trouble Not used
28 Input Z20 Active Z20 Trouble Not used
29 Input Z21 Active Z21 Trouble Not used
30 Input Z22 Active Z22 Trouble Not used
31 Input Z23 Active Z23 Trouble Not used
32 Input Z24 Active Z24 Trouble Not used
33 Input Z25 Active Z25 Trouble Not used
34 Input Z26 Active Z26 Trouble Not used
35 Input Z27 Active Z27 Trouble Not used
36 Input Z28 Active Z28 Trouble Not used
37 Input Z29 Active Z29 Trouble Not used
38 Input Z30 Active Z30 Trouble Not used
39 Input Z31 Active Z31 Trouble Not used
40 Input Z32 Active Z32 Trouble Not used
41 Input Z33 Active Z33 Trouble Not used
42 Input Z34 Active Z34 Trouble Not used
43 Input Z35 Active Z35 Trouble Not used
44 Input Z36 Active Z36 Trouble Not used
45 Input Z37 Active Z37 Trouble Not used
46 Input Z38 Active Z38 Trouble Not used
47 Input Z39 Active Z39 Trouble Not used
48 Input Z40 Active Z40 Trouble Not used
49 Input Z41 Active Z41 Trouble Not used
50 Input Z42 Active Z42 Trouble Not used
51 Input Z43 Active Z43 Trouble Not used
52 Input Z44 Active Z44 Trouble Not used
53 Input Z45 Active Z45 Trouble Not used
54 Input Z46 Active Z46 Trouble Not used
55 Input Z47 Active Z47 Trouble Not used
56 Input Z48 Active Z48 Trouble Not used
57 Input Z49 Active Z49 Trouble Not used
58 Input Z50 Active Z50 Trouble Not used
59 Input Z51 Active Z51 Trouble Not used
60 Input Z52 Active Z52 Trouble Not used
61 Input Z53 Active Z53 Trouble Not used
62 Input Z54 Active Z54 Trouble Not used
63 Input Z55 Active Z55 Trouble Not used
64 Input Z56 Active Z56 Trouble Not used
Note: 1 System Trouble excludes AC Power Fail.
Table 52 Data Formats at Annunciator Address 1
Technical Manuals Online! - http://www.tech-man.com

Notifier AFP-200 Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Auxiliary Power Output	24 VDC, 500 mA
Operating Temperature	32°F to 120°F (0°C to 49°C)
Display	80-character LCD
Power Supply	120 VAC, 60 Hz
Capacity	198 addressable devices
Notification Appliance Circuits	2
Relay Contacts	3 (Form-C)
Relative Humidity	93% non-condensing
