Notifier AFP-200 Installation Manual

Annunciator Capacity Annunciators
AFP-200 PN 15511:H2 10/14/2002 143
ACS Point # I/O Red LED Yellow LED Switch Comments
1 Input Z57 Active Z57 Trouble Not used
2 Input Z58 Active Z58 Trouble Not used
3 Input Z59 Active Z59 Trouble Not used
4 Input Z60 Active Z60 Trouble Not used
5 Input Z61 Active Z61 Trouble Not used
6 Input Z62 Active Z62 Trouble Not used
7 Input Z63 Active Z63 Trouble Not used
8 Input Z64 Active Z64 Trouble Not used
9 Input Z65 Active Z65 Trouble Not used
10 Input Z66 Active Z66 Trouble Not used
11 Input Z67 Active Z67 Trouble Not used
12 Input Z68 Active Z68 Trouble Not used
13 Input Z69 Active Z69 Trouble Not used
14 Input Z70 Active Z70 Trouble Not used
15 Input Z71 Active Z71 Trouble Not used
16 Input Z72 Active Z72 Trouble Not used
17 Input Z73 Active Z73 Trouble Not used
18 Input Z74 Active Z74 Trouble Not used
19 Input Z75 Active Z75 Trouble Not used
20 Input Z76 Active Z76 Trouble Not used
21 Input Z77 Active Z77 Trouble Not used
22 Input Z78 Active Z78 Trouble Not used
23 Input Z79 Active Z79 Trouble Not used
24 Input Z80 Active Z80 Trouble Not used
25 Input Z81 Active Z81 Trouble Not used
26 Input Z82 Active Z82 Trouble Not used
27 Input Z83 Active Z83 Trouble Not used
28 Input Z84 Active Z84 Trouble Not used
29 Input Z85 Active Z85 Trouble Not used
30 Input Z86 Active Z86 Trouble Not used
31 Input Z87 Active Z87 Trouble Not used
32 Input Z88 Active Z88 Trouble Not used
33 Input Z89 Active Z89 Trouble Not used
34 Input Z90 Active Z90 Trouble Not used Presignal Time Run Time
35 Input Z91 Active Z91 Trouble Not used Started/Release Time
36 Input Z92 Active Z92 Trouble Not used Started/Release Time
37 Input Z93 Active Z93 Trouble Not used Started/Release Time
38 Input Z94 Active Z94 Trouble Not used Started/Release Time
39 Input Z95 Active Z95 Trouble Not used Time Control Active
40 Input Z96 Active Z96 Trouble Not used Time Control Active
41 Input Z97 Active Z97 Trouble Not used Holiday Active
42 Input Z98 Active Z98 Trouble Not used Tornado Active
43 Input Z99 Active Z99 Trouble Not used Pre-Alarm Active
44 Input Not used Not used Not used
45 Input Not used Not used Not used
46 Input Not used Not used Not used
47 Input Not used Not used Not used
48 Input Not used Not used Not used
49 Input Not used Not used Not used
50 Input Not used Not used Not used
51 Input Not used Not used Not used
52 Input Not used Not used Not used
53 Input Not used Not used Not used
54 Input Not used Not used Not used
55 Input Not used Not used Not used
56 Input Not used Not used Not used
57 Input Not used Not used Not used
58 Input Not used Not used Not used
59 Input Not used Not used Not used
60 Input Not used Not used Not used
61 Input Not used Not used Not used
62 Input Not used Not used Not used
63 Input Not used Not used Not used
64 Input Not used Not used Not used
Table 53 Data Formats at Annunciator Address 2
Technical Manuals Online! - http://www.tech-man.com

Notifier AFP-200 Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Auxiliary Power Output	24 VDC, 500 mA
Operating Temperature	32°F to 120°F (0°C to 49°C)
Display	80-character LCD
Power Supply	120 VAC, 60 Hz
Capacity	198 addressable devices
Notification Appliance Circuits	2
Relay Contacts	3 (Form-C)
Relative Humidity	93% non-condensing
