Notifier AFP-200 Installation Manual

Releasing Applications Connecting Releasing Devices
156 AFP-200 PN 15511:H2 10/14/2002
Figure 147 Employing NBG-12LRA Agent Release-Abort Station with XP5 Modules
B+
B+
B-
B-
XP5-M
XP5-C
FM Approved
Releasing
Device
Push-Button
Switch set
for Relay
Push-Button
Switch set
for NAC
TB6-5 (-)
TB6-3 (+)
SLC to AFP-200
SLC
Manual
Abort
Manual
Release
47K,
1/2 w,
N-ELR
47K,
1/2 w,
N-ELR
Agent release pull station
(inside dotted lines)
Release Normal
REL-47K
N.C. Power
Supervision
Relay Contact
AFP-200
24 VDC
TB1-2 (-)
AFP-200
24 VDC
TB1-1 (+)
Power Supervision
Relay A77-716B
AFP-200
+24 VDC
TB1-1 (+)
Technical Manuals Online! - http://www.tech-man.com

Notifier AFP-200 Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Auxiliary Power Output	24 VDC, 500 mA
Operating Temperature	32°F to 120°F (0°C to 49°C)
Display	80-character LCD
Power Supply	120 VAC, 60 Hz
Capacity	198 addressable devices
Notification Appliance Circuits	2
Relay Contacts	3 (Form-C)
Relative Humidity	93% non-condensing
