How to Enter Program Change Programming
AFP-200 PN 15511:H2 10/14/2002 75
4. When a New Device screen displays, you can take one of the following actions:
Table 17 Autoprogram Options for New Devices
5. Continue displaying and acting on each device. When the control panel completes
displaying new devices, the Autoprogram Summary screen is displayed. The
Autoprogram Summary screen—see Figure 58—displays the total number of
detectors, modules, and panel circuits connected to the control panel.
Figure 58 Sample Autoprogram Summary Screen
6. Press the
ENTER key, then press the BACKSPACE key to save the program in memory
and return to the Program Change screen (Figure 53 on page 71); or
Press the
BACKSPACE key to exit without saving and return to the Program Change
screen (Figure 53 on page 71).
How to Add a Device to the Program
You can also use the Autoprogram option to add addressable detectors and modules to
the existing control panel program.
When using the Autoprogram
option with an existing
program, the control panel
does not change program
information for installed and
programmed devices.
The following steps describe how to add a new detector at SLC address 04 with
10 detectors in the existing program:
1. Install the addressable detector to the SLC at address 04 (for instructions, refer to
Section 2 “Installation”).
2. From the Program Change screen (Figure 53), press the 1 key to start autoprogram.
The Autoprogram Prompt screen (Figure 56 on page 74) appears in the LCD
display as the control panel identifies addressable devices connected to the SLC.
3. When finished identifying SLC devices, the control panel displays information for
the new detector at SLC address 04 on the LCD display as shown in Figure 59.
You can Do this
Accept default program
information for the
device
Press the ENTER key to save the default program information in
memory for the device and display the next device.
Reject the device
Press the BACKSPACE key to reject the device (which prevents
storing the device in memory) and display the next device.
Edit program
information for the
device
Use the programming keypad to edit program information for the
device. For instructions on editing program information, refer to
“How to Edit or Delete a Point (2=point)” on page 78). When finished
editing device information, press the ENTER key to save the
program information in memory for the device and display the next
device.
DETECTORS :10
MODULES :02
PANEL CKTS :04
SLC devices
(detectors and
modules) identified
during Autoprogram
The number of panel
circuits shown in the
Autoprogram Summary
screen always equals
“04.”
