Section 2 NS Series Functions 2-6 Fixed Objects
2-63
NS Series Programming Manual
No. Setting Details
5 Chamfer Set a bevel.
Type
Select one of the following three bevel choices.
None: No bevel
Radius of curve: Rounds the corners using the bevel size setting for the radius.
Cut: Cuts off an isosceles triangle from each corner based on the bevel size setting.
Size
Specify the bevel size.
N
N
N
o
o
o
t
t
t
e
e
e
♦
Only shade settings can be made for polygons and sectors.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
