Omron NS Programming Manual

Section 2 NS Series Functions 2-8 Common Functional Object Functions
2-83
NS Series Programming Manual
1
2
3
4
5
6
7
8
No. Setting Details
1 Font Name Select the font from the list.
2 Color Setting Sets the display character color.
3 Size Sets the font size. Set the magnification for raster and 7-segment fonts and
character size for vector and scalable fonts.
4 Font style Sets bold or italics.
This selection can be made only for vector fonts.
5 Vertical position Select the vertical position as the up, center, or down.
6 Horizontal position Select the horizontal position as left, center, or right.
7 Sample Displays a sample at the current settings.
8 Horizontal magnifi-
cation
With the scaled font, a magnification between 50% and 200% can be specified.
Applying Text Attribute
Text attributes such as font, size, and color can be applied to other labels. Click the Apply Attribute
Button on the Label Tab Page (or Text Attribute Tab Page) to display the Apply Text Attribute Dialog Box.
Select the attributes to be applied to other labels.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
