Section 2 NS Series Functions 2-8 Common Functional Object Functions
2-92
NS Series Programming Manual
Automatically Setting the Symbol Name or I/O Comment as the Label Text
When the communications address is set for the following functional objects, the symbol name or I/O
comment can be automatically set as the label text.
ON/OFF Buttons (when setting the Write Address)
Word Buttons (when setting the Write Address)
Bit Lamps (when setting the Display Address)
Word Lamps (when setting the Display Address)
Setting the communications
address
The name of the
communications address that
was set is automatically set in
the label.
Procedure:
1. Select
Tools – Option to display the Option Dialog Box. Open the Edit/Disp Tab.
2. Select the
Reflect to label when an address is set Option and select either the Symbol Name or I/O
comment as the label text.
Check the box as shown, and
select either
Symbol Name or I/O
Comment
for the label character
string.
3. Create the functional objects.
4. Set the communications address for each functional object from one of the following locations.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
