Omron NS Programming Manual

Section 2 NS Series Functions 2-8 Common Functional Object Functions
2-109
NS Series Programming Manual
Password
Set the password and keypad for each level from 1 to 5.
1
2
3
No. Setting Details
1 Password Set the password for each level (up to 16 alphanumeric characters).
2 Keypad
(See note.)
Select the standard system keypad or select specifying a pop-up window.
3 Specified screen
No. (See note.)
When specifying a pop-up window is selected, set the pop-up window to be opened
for password input.
Note: A pop-up window can be specified for the keypad only for PT system version 8.2 or higher.
N
N
N
o
o
o
t
t
t
e
e
e
♦
Passwords must be 16 characters maximum and can include only one-byte alphanumeric charac-
ters.
♦
Passwords can also be set under PT - Password.
If a functional object with a password set is pressed during PT operation, a Password Dialog Box will
be displayed. Press the input area to display the keyboard screen that has been set for that level. Use
this keyboard to enter the password.
Using the standard system keypad
Specify Pop-up Screen
User-specified Screen Example

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
