Omron NS Programming Manual

Section 2 NS Series Functions 2-12 Display and Input Objects
2-267
NS Series Programming Manual
Creating Temporary Input Keypads in Numeral Display and Input Objects
Use the following procedure to create a keypad using a temporary input object.
1. Position a numeral display and input object on the screen.
2. Double-click the object to display the Properties Dialog Box.
3. Display the Keypad Tab Page. Select Input from Pop-up Screen or Other Input Method (command
button etc.) under Input Method. Select the Use temporary input option under Input Method.
4. Select the Display Extension Tabs Option to display the Max/Min Tab Page. Select both the Check
Maximum Input Limit and the Check Minimum Input Limit, and select the Value option. The maxi-
mum and minimum values are set as shown in the following diagram.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
