Section 2 NS Series Functions 2-14 Alarms and Events
2-299
NS Series Programming Manual
No. Setting Details
1 Switch Switches the message display for each label.
2 Edit
Changes settings for the selected item in an alarm/event list. Click the Edit Button to
display the Alarm/Event Details Dialog Box.
3 Add
Creates a new alarm/event. Click the Add Button to display the Alarm/Event Details
Dialog Box.
4 Delete
Deletes the selected item in an alarm/event list. Click the Delete Button to display a
confirmation box and click the Yes Button to delete the item.
5 Move up/Move
down
Moves up or down the number for the item selected in the alarm/event list.
6 Import CSV
Alarm/event settings edited in CSV format can be imported from a file. Click the Import
CSV Button to display the Select alarm CSV Import Dialog Box. Select either Add to
Current Alarm or the Delete Current Alarm and click the OK button.
7 Export CSV
Alarm/event settings can be exported to CSV files. Click the Export CSV Button to
display the Export CSV Dialog Box. Specify the file name and click the Save Button.
8 Parameter Sets the screen switching when alarms or events are generated and the conditions for
saving alarm/event history. Click the Parameters Button to display the Alarm/Event
Parameters Settings Dialog Box.
9 Add Info.
Allocates the address to refer when an alarm or event occurs. Click the Add Info.
Button to display the Add Alarm/Event Info. Dialog Box.
10 Icon
Specifies a bitmap or JPEG file for the icon. Click the Icon Button to display the Details
Dialog Box.
R
R
R
e
e
e
f
f
f
e
e
e
r
r
r
e
e
e
n
n
n
c
c
c
e
e
e
♦
Messages can be set for each label for registered alarms or events.
♦
Registered alarms/events can be output in CSV format and edited as a group. Refer to Importing
and Exporting CSV Files on page 2-302 for details.
♦
The communications speed may be reduced if consecutive addresses are not set in the
Alarm/event Setting Items Dialog Box under Alarm/event setting. Set consecutive addresses if the
communications speed is slow.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
