Section 2 NS Series Functions 2-14 Alarms and Events
2-302
NS Series Programming Manual
Open the Edit/Disp Tab Window in the Option Dialog Box.
2 Select Reflect symbols in labels when setting addresses, and select either Symbol Name or I/O
Comment for the label character string.
Check the box as shown, and select
either Symbol Name or I/O Comment
for the label character string.
3 Set the communications address in the Address Field of the Alarm/Event Details Dialog Box.
4 The symbol name or I/O comment for the communications address that was set for the message
will be set automatically.
The variable name or I/O comment for the
communications address will be set automaticall
.
N
N
N
o
o
o
t
t
t
e
e
e
♦
If there are two or more labels, the symbol names and I/O comments will be set for the character
strings for all of the labels.
♦
•
Symbol names and I/O comments will not be set automatically in the following cases:
• When the communications address is replaced by another one.
• When an alarm/event was added from a CSV import.
• When the Use the String Table Option is selected.
♦
If the Reflect to label when an address is set Option is selected in the Option Dialog Box, the sym-
bol name or I/O comment will be reflected in the label of an ON/OFF Button, Word Button, Bit Lamp,
or Word Lamp when the communications address is set.
Importing and Exporting CSV Files
The CSV import and export functions are useful when there are numerous alarms or events registered
and they need to be edited efficiently.
Click the Import CSV or Export CSV Button in the Alarm/Event Settings Dialog Box.
To Next Page
