Section 2 NS Series Functions 2-14 Alarms and Events
2-320
NS Series Programming Manual
No. Setting Details
1 Selection bar Sets the color to one of the 256 colors available in the selection bar.
2 Line height Sets the height of the lines in dot units. (8 to 64 dots)
3 Display
optimization
If the Minimize column space Option is selected, the space between items on the dis-
play will be minimized.
If the Date Display Optimization Option is selected, the date will be displayed for the
leftmost item only and omitted for the other items.
4 Title line If the Display a title option is selected, the title of each item will be displayed at the top.
5 Message box
display
If the Show alarm message option is selected, the entire alarm message will be dis-
played in a message box when the alarm message area is clicked.
6 Display items
Select one of the following eight types of display items. (Multiple items can be se-
lected.)
• Group number, Display type
• Priority, Checked Time (date and time)
• No. of Occurrences
• Time: Date of occurrence
• Time: Date of recovery
• Info 1
• Info 2
• Info 3
(The Info is set in the Alarm/Event Registration Dialog Box. The Info options will not be
displayed if additional information has not been set.)
7 Ruled line
Select Display Ruled lines to display ruled lines and use the Set Button to set the color
for the lines.
8 Colors for
Showing
Status
Sets the color that indicates the status of the displayed alarm/event.
The following four types of status are used. These cannot be set when Use Text
Color/Font of Alarm/Event Setting is selected on the Text Attributes Tab Page.
• Occurring Unchecked
• Occurring Checked
• Canceled Unchecked
• Canceled Checked
Text Tab Page
Sets the text attributes, such as font and color, for the display string.
When Use Text Color/Font of Alarm/Event Setting is selected, the display will be in the color and font
set under PT - alarm/event setting. Refer to Text Attribute in 2-8 Common Functional Object Functions
and Outline in 2-13 Alarms and Events.
Background Tab Page
Sets the background color for alarm/event summary or history display from 256 color options. Refer to
Background and Setting Color under 2-8 Common Functional Object Functions for details.
Icon Tab Page
Selects the icon to operate alarm/event summaries and histories.
