Section 1 Overview 1-3 Communicating with the Host
1-26
NS Series Programming Manual
Address Operation Classification
20 ID number for cleared alarms and events
21 Alarm/event ID when alarm/event object macro executed
(Stores the displayed or selected alarm or event ID number when a
macro is executed using an alarm/event object.)
22 Reserved (Do not access.)
−
23 Macro execution error number
(The error is ignored when the number is 0. The value will be held
when an error is detected until 0 is written using a user macro or func-
tional object.)
24 Macro error screen number
(FFFFh for project macros.)
25 Macro error object ID number
(FFFFh for project/screen macros.)
26 Error macro execution timing
0: When loading a project
4: Alarm/Event ON
5: Alarm/Event OFF
10: When loading a screen
11: When unloading a screen
20: Touch ON
21: Touch OFF
22: Before inputting numeral and string
23: Before writing numeral and string
25: Before changing numeral and string
26: When selecting a list
30: When pressing alarm/event display area
31: When selecting alarm/event summary and history
NS status notification
27 Offset value for index I0
28 Offset value for index I1
29 Offset value for index I2
30 Offset value for index I3
31 Offset value for index I4
32 Offset value for index I5
NS status control
33 Offset value for index I6
34 Offset value for index I7
35 Offset value for index I8
36 Offset value for index I9
37 Data log group number
38 Data block error number NS status notification
39 Authentication level
40 Range for Initializing Alarm/Event History Makes the optional settings
for initialization of alarm/event histories using $SB32.
The alarm/event history to be initialized using the value stored at
$SW40 can be specified as follows.
0: All alarm/event history data
1: Confirmed alarm/event history data only
2: Cleared alarm/event history data only
3: Cleared and confirmed alarm/event history data only
4: Resolved alarm/event history data and number of occurrences
NS status control
