Section 2 NS Series Functions 2-17 Data Blocks
2-388
NS Series Programming Manual
Calculating Data Bytes for Data Blocks
This section explains how to calculate the data quantity for data blocks.
Example:
String Field
8 characters × 2
bytes/character
+
Numeral Field
4 bytes
+
Numeral Field
4 bytes
+
Numeral Field
8 bytes
1 record = [8 characters × 2 bytes/character]+[4 bytes]+[4 bytes]+[8 bytes]= 32 bytes
100 records = 32 bytes/record × 100 records = 3,200 bytes
R
R
R
e
e
e
f
f
f
e
e
e
r
r
r
e
e
e
n
n
n
c
c
c
e
e
e
♦
The record labels are not calculated in the data quantity. Refer to Creating Data Files on page
2-397 for record labels.
Data Block 1
Product
name
Product
No.
Width Depth Height
0 Product A1
String,
8 characters
Numeral, INT Numeral, DINT Numeral, REAL
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
99
Product
A99
String,
8 characters
Numeral, INT Numeral, DINT Numeral, REAL
Record label
