Omron NS Programming Manual

Section 2 NS Series Functions 2-18 System Clock
2-408
NS Series Programming Manual
No. Setting Details
4 Apply to All
Labels
Uses the date display method of the selected label for all labels. Apply to All Labels cannot
be set in the following cases.
• When the Date & Time Display Format Check Box is selected on the Edit/Display Tab
Page of the Option Dialog Box accessed by selecting
Tools - Option.
• When there is only one label.
5 Use Large
keypad
Select
Use Large keypad to use a large Setting Dialog Box (keypad). A 252 × 268 dot
(V
× H) keypad will be displayed during PT operation.
Text Tab Page
Sets the text attributes, such as font and color, for the date display. Refer to Text Attributes under 2-8
Common Functional Object Functions for details.
Background Tab Page
Sets the background color for date display from a selection of 256 colors. Refer to Background and
Setting Colors under 2-8 Common Functional Object Functions for details.
De-select (i.e., remove the tick from) Tile background to have a transparent background.
Frame Tab Page
Specifies the colors and sizes of the object frame to change the shape or color when the button is de-
pressed or raised. Refer to Frames under 2-8 Common Functional Object Functions for details.
Flicker Tab Page (Extension Tab)
Makes flicker settings to make the object flicker (flash). Refer to Flicker under 2-8 Common Functional
Object Functions for details.
Write (Extension Tab)
Confirms the write operation using a dialog box before the date is set. The confirmation message can
be changed. Refer to Write Settings under 2-8 Common Functional Object Functions for details.
Password Tab Page (Extension Tab)
A password can be set for when the object area is pressed. Five passwords of up to 16 characters
each can be set. One password can be requested for each object. Refer to Passwords under 2-8
Common Functional Object Functions for details.
Control Flag Tab Page (Extension Tab)
Control flags control the input and display of functional objects. Use control flags to enable display or
input when the contents of an address turn ON or OFF. Refer to Control Flags under 2-8 Common
Functional Object Functions for details.
Size/Position Tab Page (Extension Tab)
Sets the object size and position. Refer to Size/Position under 2-8 Common Functional Object Func-
tions for details.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
