Omron NS Programming Manual

Section 5 Troubleshooting and Maintenance 5-2 Error Messages
5-8
NS Series Programming Manual
Message Cause Possible countermeasure
Failed to process the
CX-Server.
CX-Server may not be in-
stalled correctly.
CX-Server may not be installed correctly.
Refer to Section 2 Setup, Starting, and
Exiting in the CX-Designer User’s Manual
and uninstall CX-Server then reinstall
CX-Designer and CX-Server.
Error detected at NS Hardware.
(0x03a6)
Unexpected error. The PT may need repaired. Contact your
nearest OMRON representative.
NS hardware error. Possible PT hardware error. The PT may need repaired. Contact your
nearest OMRON representative.
Cannot execute because an
invalid address exists. Check
with the Find Invalid Addresses
in the Symbol Table.
The host type (Type) was
changed in the CX-Designer’s
Comm. Setting Dialog Box,
but the communications ad-
dress was created in an area
that does not exist in that
host. The user attempted to
transfer a project containing
that invalid address.
If there is an invalid address, the project
cannot be transferred. Find the invalid
address by right clicking the Find Invalid
Addresses Button in the CX-Designer’s
Symbol Table Window and correct the
address.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
