Section 5 Troubleshooting and Maintenance 5-2 Error Messages
5-32
NS Series Programming Manual
Message Cause Possible countermeasure
Addressing error exists in the
screen, alarm, data log, or
macro. Correct address setting
by the CX-Designer.
Screen No.: XXXX
Allocation Host: XXXX
Allocation Address: XXXX
General=0
XXX,
Additional=0XXX XXXX
NS5:
Addressing error exists in the
screen, alarm, data log or
macro.
Screen No.: XXXX
Allocation Host: XXXX
Allocation Address: XXXX
General=0
XXX,
Additional=0
XXX XXXX
An illegal address is
set.
Press the OK Button to go to the System
Menu. Select Data Check to see whether the
address is valid and the communications
settings are correct. Use CX-Designer to
change settings if necessary.
Communication error
detected while uploading by the
following cases:
Corrupted data by noise
Transmit error by the host
Allocation Host: XXXX
NS5:
Communication error detected
while uploading the data
Allocation Host: XXXX
Data corrupted by
noise
Invalid host communi-
cations command
Check the cable connection and conduct a
continuity test. Replace the cable if there is a
cable error, or rewire the cable if necessary.
Failed to read host registration.
Correct host registration with
CX-Designer. Then, press OK
and then download project data.
Project data cannot be
downloaded (was not
transmitted or is cor-
rupted).
Use a Programming Device to repair the
data and try to download it again.
Time-out error occurred while
writing by the following case:
Disconnection of the
connecting cable
Stopped host_- Incorrect
time-out period
Allocation Host: XXXX
Do you want to retry?
NS5:
Time-out error occurred while
writing the data
Allocation Host: XXXX
Do you want to retry?
The communications
cable is not properly
connected. The host
communications
service has stopped.
The timeout monitoring
time is too short.
Check the cable connection and conduct a
continuity test. Replace the cable if there is a
cable error, or rewire the cable if necessary.
To Next Page
