Appendices Appendix-1 Specifications
A-2
NS Series Programming Manual
Item Specification
List selection
objects
• Reference file format
File name (up to 8 characters) +.LST
• Operations at list selection
Display/no display of selected bar.
Store selected line number to specified address.
Store selected line character string to specified address.
• Character display format
ASCII code (Shift JIS), Unicode.
• No. of characters per line
Up to 256.
• Maximum number of display lines
1,024.
Thumbwheel
switches
• No. of displayable digits
Integer part: Up to 15 digits
Decimal fraction part: Up to 10 digits.
(Decimal fraction input is enabled only when the display format is set to decimal
and scaling is set, or when real number storage is set.)
• Input method
+ and – Buttons.
Analog meters • Display direction
Up, down, left, right.
• Incremental direction
Clockwise, counterclockwise.
• Shape
Quarter circle, half circle, circle.
• Display format
Colored, needle.
• Needle type
Straight line, arrow, triangular arrow
• Needle width
1 to 3 dots
Level display
objects
• Display direction
From bottom to top, top to bottom, right to left, left to right
• Coloring
3 levels
Broken-line graphs • No. of graph points per broken line
Up to 1000.
• No. of displayable graphs per broken-line graph
Up to 256.
• No. of graphs that can be registered per project
Up to 16.
• No. of graphs that can be registered per group
Up to 256.
• Amount of data that can be stored in log
300,000 bytes
Bitmaps • Displayable file formats
BMP, JPEG (RLE and progressive jpeg are not supported.)
Alarm/Event display
objects
• Display format
Fixed character, flowing text
• Maximum number of display objects
5,000
Alarm/Event
summary and
history objects
• Display data
Current alarms/events, alarm/event history.
• Maximum number of display objects
2,048 (for histories).
Date objects • Date displayed on PT (year, month, day)
• Display format: 27 types.
