Appendices Appendix-1 Specifications
A-3
NS Series Programming Manual
Item Specification
Time objects • Time displayed on PT (hour, minute, seconds)
• Display format: 8 types.
Data log graphs • No. of log points
1 to 50,000.
• No. of data logs per project
Up to 100 groups.
• No. of logging points per project
Up to 160,000 (NS5: 120,000 points)
• No. of addresses that can be recorded to 1 group
Up to 16.
• No. of addresses for standard logging
Up to 128.
• Number of always logging points
50,000 max.
Data Block Table • Maximum number of records
Up to 1,000 lines
• Maximum number of fields
Up to 500 columns
• Data Quantity for 1 Data Block
524,288 bytes
Video Display • Maximum number of simultaneous display channels
NS-CA001: 4ch (320×240 size only)
NS-CA002: 1ch
• Input method NTSC/PAL
NS-CA001: NTSC/PAL
NS-CA002: Analog RGB or NTSC/PAL
Consecutive Line
Drawing
• Number of vertices
Up to 128 points
Multifunction Object
• Shape
Select Shape, Single-lined Circle, Single-lined Rectangle, Double-lined Circle,
Double-lined Rectangle, Rectangle 2 Light, Polygon, Sector
• Change Color/Shape
Up to 16 types
Contents Display • String, bmp file, jpg file (RLE-format bmp files and progressive jpeg are not
supported).
• No. of characters
Up to 1,024. Line wrapping is possible.
Graphic display (fixed) • Displayed at any position.
Rectangle, circle, ellipse, line, polyline, polygon, sector, arc.
• Up to 2,048 graphic displays can be created per screen.
Frames • Up to 10 can be created per screen.
• Up to 256 functional objects can be created per frame page.
However, a limit of 1,024 functional object per screen applies, and this may restrict
the number of objects per frame.
Tables • No. of tables
Any number of tables can be created, as long as the total number of functional
objects per screen does not exceed 1,024.
• Horizontal
Up to 30 columns.
• Vertical
Up to 40 lines.
• No. of functional objects per table
Up to 256.
Libraries • Up to 4,096 libraries can be registered.
To Next Page
