Appendices Appendix-1 Specifications
A-4
NS Series Programming Manual
Item Specification
User screens • Up to 4,000 screens, including base and pop-up screens, can be created per
project.
• Up to 3 pop-up screens can be overlapped.
Sheets • Up to 32 sheets can be created per project.
• Up to 10 sheets can be set for layered display on standard screens.
• Up to 1,024 functional objects, including those inside frames and tables, can be
created per sheet. Up to 2,048 graphic displays can be created per sheet.
No. of label switches • Up to 16.
Background screen
files
• Displayable file formats
BMP, JPEG (RLE-format bmp files and progressive jpeg are not supported.)
Background colors 256
Project registration
method
Transfer from CX-Designer Data transfer (under File/Data transfer) to PT.
• PT - Transfer - Transfer [To PT]
• PT - Transfer - Quick Transfer [To PT]
• PT - Transfer - Transfer Program
N
N
N
o
o
o
t
t
t
e
e
e
♦
With project data versions lower than 8.0, a maximum total of 1,024 objects (including functional
objects, frames, tables, and graphic displays) can be created per screen.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
