Appendices Appendix-4 Addresses for Functional Objects
A-23
NS Series Programming Manual
Functional
object
Tab page name Set address B W D S
General Indirect specification of the file location OK No No No Command
Buttons
Indirect specification of the record method OK No No No
Executed when the specified address changes
from OFF to ON
OK No No No
Color/Shape Indirect background color specification No OK No No
Label Indirect specification of label character color No OK No No
Flicker Flicker specification OK No No No
Control Flag Input enabled/disabled flags OK No No No
Display/no display flags OK No No No
General Display address OK No No No
Indirect specification of background color when
ON
No OK No No Color/Shape
Indirect specification of background color when
OFF
No OK No No
Label Indirect specification of label character color No OK No No
Flicker Flicker specification OK No No No
Bit lamps
Control Flag Display/no display flags OK No No No
General Display address No OK No No
Indirect specification of background color when 0 No OK No No
Indirect specification of background color when 1 No OK No No
Indirect specification of background color when 2 No OK No No
Indirect specification of background color when 3 No OK No No
Indirect specification of background color when 4 No OK No No
Indirect specification of background color when 5 No OK No No
Indirect specification of background color when 6 No OK No No
Indirect specification of background color when 7 No OK No No
Indirect specification of background color when 8 No OK No No
Color/Shape
Indirect specification of background color when 9 No OK No No
Label Indirect specification of label character color No OK No No
Flicker Flicker specification OK No No No
Word lamps
Control Flag Display/no display flags OK No No No
Background Indirect background color specification No OK No No
Indirect specification of label character color No OK No No Label
Indirect specification of label string file line No OK No No
Message Address for switching status No OK No No
Frame Indirect specification of frame ON/OFF OK No No No
Flicker Flicker specification OK No No No
Label objects
Control Flag Display/no display flags OK No No No
Numeral display
& input objects
Communications address No OK
(See
note 1.)
OK
(See
note 1.)
No
General
Indirect specification of units/scale number No OK No No
Text Attributes Indirect specification of numeral/character color No OK No No
Background Indirect background color specification No OK No No
Frame Indirect specification of frame ON/OFF OK No No No
Indirect specification of input upper limit No OK
(See
note 1.)
OK
(See
note 1.)
No
Input Upper and
Lower Limits
Indirect specification of input lower limit No OK
(See
note 1.)
OK
(See
note 1.)
No

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
