Omron NS Programming Manual

Appendices Appendix-4 Addresses for Functional Objects
A-24
NS Series Programming Manual
Functional
object
Tab page name Set address B W D S
Indirect specification of upper limit monitoring No OK
(See
note 1.)
OK
(See
note 1.)
No
Numeral display
& input objects
Limit Monitor
Indirect specification of lower limit monitoring No OK
(See
note 1.)
OK
(See
note 1.)
No
Flicker Flicker specification OK No No No
Write Settings Write notification address OK No No No
Input enabled/disabled flags OK No No No
Display/no display flags (all) OK No No No
Control Flag
Display/no display flags (numerals) OK No No No
String
display & input
objects
General String start address No OK
(See
note 2.)
No OK
Text Attributes Indirect character color specification No OK No No
Background Indirect background color specification No OK No No
Frame Indirect specification of frame ON/OFF OK No No No
Flicker Flicker specification OK No No No
Write Settings Write notification address OK No No No
Input enabled/disabled flags OK No No No
Control Flag
Display/no display flags OK No No No
List data address No No No No General
Indirect file line specification No OK No No
Background Indirect background color specification No OK No No
Selection line number address No OK No No Selection
Operation
Selection line string address No OK
(See
note 2.)
No OK
Frame Indirect specification of frame ON/OFF OK No No No
Flicker Flicker specification OK No No No
Input enabled/disabled flags OK No No No Control Flag
Display/no display flags OK No No No
Display block number specification address No OK No No
Address specifying display start line No OK No No
List selection
objects
External Control
List re-display specification OK No No No
General Communications address No OK
(See
note 1.)
OK
(See
note 1.)
No
Text Attributes Indirect specification of numeral/character color No OK No No
Background Indirect background color specification No OK No No
Indirect specification of input upper limit No OK
(See
note 1.)
OK
(See
note 1.)
No
Upper/lower
Limits
Indirect specification of input lower limit No OK
(See
note 1.)
OK
(See
note 1.)
No
Flicker Flicker specification OK No No No
Write Settings Write notification address OK No No No
Input enabled/disabled flags OK No No No
Thumbwheel
switches
Control Flag
Display/no display flags OK No No No

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
