Omron NS Programming Manual

Appendices Appendix-4 Addresses for Functional Objects
A-25
NS Series Programming Manual
Functional
object
Tab page name Set address B W D S
General Communications address No OK
(See
note 1.)
OK
(See
note 1.)
No
Analog
meters
Border Indirect specification of border value (maximum) No OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect specification of border value (delimiter 1) No OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect specification of border value (delimiter 2) No OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect specification of border value (minimum) No OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect specification of range 1 color No OK No No
Indirect specification of range 2 color No OK No No
Color
Indirect specification of range 3 color No OK No No
Indirect background color specification No OK No No
Indirect specification of range 1 background color No OK No No
Indirect specification of range 2 background color No OK No No
Background
Indirect specification of range 3 background color No OK No No
Flicker Flicker specification OK No No No
Control Flag Display/no display flags OK No No No
Level meters General Communications address No OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect specification of border value (maximum) No OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect specification of border value (delimiter 1) No OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect specification of border value (delimiter 2) No OK
(See
note 1.)
OK
(See
note 1.)
No
Border
Indirect specification of border value (minimum) No OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect specification of range 1 color No OK No No
Indirect specification of range 2 color No OK No No
Color
Indirect specification of range 3 color No OK No No
Frame Indirect specification of frame ON/OFF OK No No No
Indirect background color specification No OK No No
Indirect specification of range 1 background color No OK No No
Indirect specification of range 2 background color No OK No No
Background
Indirect specification of range 3 background color No OK No No
Flicker Flicker specification OK No No No
Control Flag Display/no display flags OK No No No
Display refresh bit OK No No No Broken-line
Graphs
General
No. of display-enabled points No OK No No
Graph Graph data OK OK
(See
note 1.)
(See
note 2.)
OK
(See
note 1.)
(See
note 2.)
No

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
