Omron NS Programming Manual

Appendices Appendix-4 Addresses for Functional Objects
A-26
NS Series Programming Manual
Functional
object
Tab page name Set address B W D S
Graph Indirect specification of number of graph points No OK No No Broken-line
Graphs
Indirect specification of maximum graph data
value
OK OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect specification of minimum graph data
value
OK OK
(See
note 1.)
OK
(See
note 1.)
No
Background Indirect background color specification No OK No No
Flicker Flicker specification OK No No No
Input enabled/disabled flags OK No No No
Control Flag
Display/no display flags OK No No No
General Address for indirect specification of display file No OK No No
Frame Indirect specification of frame ON/OFF OK No No No
Flicker Flicker specification OK No No No
Bitmaps
Control Flag Display/no display flags OK No No No
Alarm/event data OK No No No General
Alarm and event information OK OK No No
Flowing Text Specification of flowing text display start OK No No No
Background Indirect background color specification No OK No No
Frame Indirect specification of frame ON/OFF OK No No No
Flicker Flicker specification OK No No No
Input enabled/disabled flags OK No No No
Alarm/event
display
objects
Control Flag
Display/no display flags OK No No No
Selected alarm ID write address No OK No No
Alarm/event data OK No No No
General
Alarm information OK OK No No
Background Indirect background color specification No OK No No
Frame Indirect specification of frame ON/OFF OK No No No
Flicker Flicker specification OK No No No
Input enabled/disabled flags OK No No No
Alarm/event
summary and
history objects
Control Flag
Display/no display flags OK No No No
Background Indirect background color specification No OK No No
Frame Indirect specification of frame ON/OFF OK No No No
Flicker Flicker specification OK No No No
Input enabled/disabled flags OK No No No
Date objects
Control Flag
Display/no display flags OK No No No
Background Indirect background color specification No OK No No
Frame Indirect specification of frame ON/OFF OK No No No
Flicker Flicker specification OK No No No
Input enabled/disabled flags
OK No No No
Time objects
Control Flag
Display/no display flags
OK No No No
Graph data OK OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect specification of maximum graph data
value
OK OK
(See
note 1.)
OK
(See
note 1.)
No
Data log graphs General
Indirect specification of minimum graph data
value
OK OK
(See
note 1.)
OK
(See
note 1.)
No

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
