Omron NS Programming Manual

Appendices Appendix-4 Addresses for Functional Objects
A-27
NS Series Programming Manual
Functional
object
Tab page name Set address B W D S
Display Indirect specification of time axis No OK No No Data log graphs
Time axis data destination No No No No
Time axis data enable/disable bit OK No No No
Display refresh notification OK No No No
Scroll seconds specification No OK No No
Time data transmission destination No OK
(See
note 2.)
No No
Background Indirect background color specification No OK No No
Flicker Flicker specification OK No No No
Input enabled/disabled flags OK No No No
Control Flag
Display/no display flags OK No No No
General Frame page number No OK No No
Input enabled/disabled flags OK No No No
Frame
objects
Control Flag
Display/no display flags OK No No No
Address for numeral field No OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect reference of maximum limit for numeral
field
No OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect reference of minimum limit for numeral
field
No OK
(See
note 1.)
OK
(See
note 1.)
No
Address for string field No OK
(See
note 2.)
No OK
General
Specify interlock OK No No No
Text Attribute Indirect specification of text colors No OK No No
Write Setting Write notification address OK No No No
Input enable/disable flag OK No No No
Data block
tables
Control Flag
Display enable/disable flag OK No No No
Indirect specification of color
No OK No No
Indirect specification of the number of vertices
No OK No No
Consecutive
Line Drawing
General
Starting address of the X-Y coordinates data
No OK
(See
note 2.)
No No
General
Input
OK No No No
Perform an action when a bit value changes
OK No No No
Perform an action when a word value changes
No OK No No
Multifunction
Object
Write bit
OK No No No
Write word – write address
No OK
(See
note 1.)
OK
(See
note 1.)
No
Write word – indirect specification of value
No OK
(See
note 1.)
OK
(See
note 1.)
No
Write word – indirect specification of upper limit
No OK
(See
note 1.)
OK
(See
note 1.)
No
Write word – indirect specification of upper limit
No OK
(See
note 1.)
OK
(See
note 1.)
No
Write string
No OK
(See
note 2.)
No OK
