Remove a Front Indicator Panel

7.

Disconnect the small cable from the panel and remove the panel completely

from the server.

Related Information

■

“Install a Front Indicator Panel” on page 222

■

“Front Indicator Panel Controls and LEDs” on page 46

Servicing the Front Indicator Panel 221
