4.4.3. Document Skew
Remove any obstacles
from the document path.
Are there any obstacles
in the document path?
Are the components of the
Feeder Unit operational?
Does the NP Sensor
Actuator move smoothly?
Are the Pre-Feed and ADF
Rollers operational?
Replace the Pre-Feed
and / or ADF Roller.
Replace any worn out /
defective component.
Adjust or replace the
Actuator.
Ye s
No
Ye s
No
Ye s
No
No
No
Adjust Feed Skew
Adjustment "A".
(See Sect. 4.4.3.1.)
Front Page skew?
Ye s
Ye s
Adjust Feed Skew
Adjustment "B".
(See Sect. 4.4.3.1.)
Back Page skew?
Ye s
No
START
END
