5.2.5. Fax Service Mode 4 (Modem Test)
5.2.5.1. Binary Signal
This Service Mode is used to check the binary signal output. Signals can be output to the line using the
following procedure.
Select the "04 MODEM Tests" on the Touch Panel display.
↓
Select the "01 Binary Signal" on the Touch Panel display.
↓
Select the desired parameter on the Touch Panel display and touch the "CLOSE".
↓
Touch the "OK" button 3 times.
↓
Press "FUNCTION" and "C (CLEAR)" keys simultaneously to exit the service mode.
Binary Signal Table
Number Signals
1 V21 300bps
2 V27ter 2400bps
3 V27ter 4800bps
4 V29 7200bps
5 V29 9600bps
6 V17 TC7200bps
7 V17 TC9600bps
8 V17 12000bps
9 V17 14400bps
