Panasonic DP-2330

193
DP-2330/3030
MAR 2005
Ver. 2.1
DP-2310/3010
5.1.5. F6 Mode: Adjust Parameters (For Copier)
Set the machine to Service Mode and press "6" key on the Keypad.
↓
Press the "START" key.
↓
Select the desired code number on the Touch Panel display.
↓
If you wish to select another code number, scroll the menu with the arrow buttons.
↓
Select the desired function on the Touch Panel display and touch the "OK" button.
↓
When the "C (CLEAR)" key is touched, the selected code input will not be accepted.
↓
Press "FUNCTION" and "C (CLEAR)" keys simultaneously to exit the service mode.
↓
Reboot the machine after setting the parameter(s) to activate the setting(s).
Note:
The Factory Setting is different in each model.
F6 Mode
No. Item Remarks
Setting
Range
00 Adj 100% Side-Side Read Adjustment of ratio for vertical position when
scan is made.
-9 - +9 0.1%
01 Adj 100% Lead-Tail Read Adjustment of ratio for parallel position when
scan is made.
-9 - +9 0.1%
02 100% Selection Adjustment from 99.1% to 100.9% -9 - +9 0.1%
03 Original Registration Adjustment of platen original registration
detection timing.
-30 - +30
0.2mm
04 Printer Registration Delay time is adjusted from registration roller
clutch ON.
-50 - +50
0.5mm
05 Main Motor Speed Adjustment of Main Motor speed. -10 - +10
0.1%
06 Polygon Motor Speed Adjustment Polygon Motor speed. -5 - +5 0.1%
07 Registration Void Registration void should be adjusted. 0 - +99
0.5mm
08 Trail Edge Read Timing Adjustment of trail edge void. -9 - 0
0.5mm
09 Trail Edge Print Timing Adjustment of trail edge void. -9 - +15
0.5mm
10 Side Adjust (Bypass) Adjustment of LSU side-side (Sheet Bypass). -8 - +7
0.5mm
11 Side Adjust (Tray 1) Adjustment of LSU side-side (1st Tray). -8 - +7
0.5mm
12 Side Adjust (Tray 2) Adjustment of LSU side-side (2nd Tray). -8 - +7
0.5mm
13 Side Adjust (Tray 3) Adjustment of LSU side-side (3rd Tray). -8 - +7
0.5mm
14 Side Adjust (Tray 4) Adjustment of LSU side-side (4th Tray). -8 - +7
0.5mm
