Panasonic DP-2330

32
DP-2330/3030
MAR 2005
Ver.2.1
DP-2310/3010
1.5. External View
1. Standard Configuration
2. With Optional System Console Configuration
33.86 in (860 mm)
27.44 in (697 mm)
23.58 in (599 mm)
27.83 in (707 mm)
Manufacturer's Name and Address
Factory ID
Product complies with DHHS Rules 21
CFR Subchapter J in effect at date
of manufacture.
(For USA Only)
Front View
Right View
Left View
Top View
Rear View
CAUTION
!
THIS PRODUCT CONTAINS A LITHIUM BATTERY. DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED.
REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE. DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS OF YOUR LOCAL SOLID WASTE OFFICIALS.
45.98 in (1168 mm)
12.05 in
(308 mm)
14.84 in
(377 mm)
Front View
Right View
Left View
Top View
Rear View
