Panasonic DP-2330

254
DP-2330/3030
MAR 2005
Ver.2.1
DP-2310/3010
6.7. Glossary of Electrical Abbreviations
Signal Name Function
+12V +12 VDC Power Supply
+24V +24 VDC Power Supply
+24VD1 +24 VDC Power Supply
+24VD2 +24 VDC Power Supply
+24VHL +24 VDC Power Supply
+24VFB +24 VDC Power Supply
+24VFL +20/+24 VDC Power Supply
+24VFP +24 VDC Power Supply
+24VM +24 VDC Power Supply
+24VOPC +24 VDC Power Supply
+24VOPF +24 VDC Power Supply
+3.3V +3.3 VDC Power Supply
+5V +5 VDC Power Supply
+5VD +5 VDC Power Supply
+5VP +5 VDC Power Supply
24ELS Scanner 24V Sensor Error Signal
ACL AC Power Supply
ACLRLB AC Power Supply
ACN AC Power Supply
ACNRLB AC Power Supply
ACSW Fuser Relay
AGND Ground
BD_A Beam Detect A
BMCNT Toner Bottle Motor Control Signal
BTHP Toner Bottle Position Sensor Signal
BZCLK Buzzer Signal
BZOFF Buzzer OFF
CDSN1 Density Sensor 1 Signal
CDSN2 Density Sensor 2 Signal
CDSSOL Density Sensor Solenoid
CR0 Charge Control AC Clock
CR1 Charge Control DC ON/OFF PWM
CR1 Charge Control AC Current
CSSRXD CSS Reception Data
CSSTXD CSS Transmission Data
DAA1 ADF Motor Current Control Signal
DADATA D/A Converter Serial Data
DACLK D/A Converter Serial Clock
DALTH D/A Converter Serial Latch
DR0 Development Control AC ON/OFF PWM
DR1 Development Control DC ON/OFF PWM
DUPCLH1 ADU Clutch Control Signal
ELPCNT Discharge Lamp
FLNG Inverter Control Signal
GACLK+ Gate Array Clock +
