3.2. Required Tools
3.2.1. Preventive Maintenance Method
No. Tools No. Tools
1 Soft Cloth 7 Pliers
2 Isopropyl Alcohol 8 Cotton Swab
3 Phillips Screwdriver (#2) 9 Brush
4 Stubby Phillips Screwdriver (#2) 10
KS-660 - Conductive Grease
(Available from Shin-Etsu Silicones of America, Inc.
URL: http://www.shinetsusilicones.com)
5 Slotted Screwdriver (3/32 in) 11
Molykote EM-50L Grease
(Available from Dow Corning,
URL: http://www.dowcorning.com)
6Tweezer
No. Part Description
Important
Action
Comments
1 Memory Data Check 1. Print the RAM DATA for reference and as a pre-caution.
2. After completing the task(s), print and compare the RAM
DATA with the previously printed one.
2 Auto Document
Feeder (ADF)
Check &
Clean
1. Clean the Rollers and Separation Rubber with Isopropyl
Alcohol when required.
3 Scanner Unit Check &
Clean
1. Clean the Scanning Glass or White Seal Guide with
Isopropyl Alcohol when required.
4 Transmitter Unit Check &
Clean
1. Remove any foreign obstacles.
2. Clean the Rollers with Isopropyl Alcohol when required.
5 Mirrors Check &
Clean
1. Do not touch the surface of the Mirrors with your hands.
Clean any dirt or fingerprints with a soft cloth, saturated with
Isopropyl Alcohol.
6 Inspection Items Check 1. Check the Harnesses.
2. Check the Connectors.
3. Check the Screws. If required, replace consumable parts.
7 Gears, Rollers Shafts Check &
Grease
1. Check and grease the required Gears and Shafts.
8 Timing Belts Check &
Clean
1. Check the belts for looseness or abrasion.
2. Adjust the Idle Pulley.
