Panasonic DP-2330

91
DP-2330/3030
MAR 2005
Ver. 2.1
DP-2310/3010
3.4. Preventive Maintenance Check List
No.
Mechanical Parts
Ref.
No.
Cleaning Replacement/Adjustment
Ref.
Counter
Cycle
(Sheet)
Method
Cycle
(Sheet)
Procedure
i-ADF/ADF Unit
1 ADF Roller 1728 60K Alcohol 120K Refer to
2.2.1.
F7-02-03
2 Pre Feed Roller 1731 60K Alcohol 120K
3 Separation Roller 1740 60K Alcohol 120K
4 Torque Limiter
Bushing
1741 60K Alcohol 120K
5 Torque Limiter
Spring
1742 60K Alcohol 120K
Scanner Unit
6 Slider 211 - - 600K Refer to
2.2.3.
F7-02-02
7 Mirror 1 264 60K - -
8 Mirror 2 265 60K - -
9 Glass L Assembly 557 60K - -
10 Glass S 559 60K - -
Paper Feed Module
11 Registration Roller 1121 60K Alcohol 480K Refer to
2.2.9.
F7-03-01/-
02/-03/-04
12 Reverse Clutch 1132 - - 120K
13 Paper Feed Roller 1144 60K Alcohol 120K
14 C25 Gear Roller 1145 60K Alcohol 120K
15 Reverse Clutch
Assembly
1146 - - 120K
16 Roller Cleaner 1229 60K Dry soft cloth 240K F7-02-01
17 Separator Pad 1242 - - 60K
Reverse Roller 1291 60K Alcohol 120K F7-03-00
18 Feed Roller 1244 60K Alcohol 120K
19 Intermediate Roller 2306 60K Alcohol - F7-02-01
Bias Transfer Unit
20 Bias Transfer Roller
(BTR)
1221 60K Dry soft cloth 120K Refer to
2.2.7.
F7-02-01
21 CDS PC Board 1986 60K Dry soft cloth -
Process Unit
- Developer - - - 120K Refer to
2.2.4.
F7-02-09
22 Cleaning Blade 704 - - 120K F7-01-06
23 Cleaning Roller 706 - - 120K
24 Scoop Sheet 710 - - 120K
25 OPC Drum 716 - - 60K F7-02-05
26 Front Cleaning Felt 717 - - 120K F7-02-06
27 Rear Cleaning Felt 718 - - 120K
28 Cleaning Sponge 720 - - 120K
29 Bias Charge Roller 725 60K Dry soft cloth 120K
