92
DP-2330/3030
MAR 2005
Ver.2.1
DP-2310/3010
Note:
1. Wet Cloth represents a soft cloth saturated with water.
2. The Maintenance Cycle is based on the Counter Information for each individual module.
To verify the counter information, print the Total Counter List using the Service Mode: F7 - Electronic
Counter - 00 (List Print).
3. Cleaning, Replacement and Adjustment Cycle (Sheet) are based on using Panasonic's recommended
standard paper and supplies. These cycles may vary with the kind of paper used and/or ambient
conditions.
Fuser Unit
30 Fuser Roller Gear 1014 - - 480K Refer to
2.2.5.
F7-02-00
31 Fuser Roller 1026 60K Alcohol 240K
32 Pressure Roller 1027 60K Alcohol 480K
33 Thermostat 1038 60K Dry soft cloth - Refer to
2.2.5.
F7-02-00
34 Bearing 1039 - - 240K
35 Thermistor
Assembly
1041 60K Dry soft cloth 480K
36 Fuser Lamp (450W) 1043 - - 240K
37 Fuser Lamp (600W) 1044 - - 240K
38 Fuser Roller Bearing 1046 - - 240K
39 (Available for Japan
Only)
--- -
40 Upper Finger 1067 60K Alcohol 480K
41 Web Pressure Roller 1080 - - 480K
42 Cleaning Web Roller 1083 - - 120K F7-02-08
Dual-Path Exit Guide
43 Feed Roller 1510 60K Alcohol - Refer to
2.2.5.
F7-02-01
44 Idle Roller 1511 60K Alcohol -
Automatic Duplex Unit
45 Drive Roller 1409 60K Alcohol - Refer to
2.2.7.
F7-03-06
46 Drive Roller 2 1410 60K Alcohol -
Paper Transportation
47 Drive Roller 1314 60K Alcohol - Refer to
2.2.11.
F7-02-01
No.
Mechanical Parts
Ref.
No.
Cleaning Replacement/Adjustment
Ref.
Counter
Cycle
(Sheet)
Method
Cycle
(Sheet)
Procedure
To Next Page
