Panasonic DP-2330

156
DP-2330/3030
MAR 2005
Ver.2.1
DP-2310/3010
Note:
These error codes will appear only when the optional accessories are installed. Refer to the appropriate
Optional Unit Service Manual.
Technician Warning:
The following message will be displayed in the event that the required Additional Sort Memory to operate
the HDD is not installed.
E7- 27 Finisher Tray Shift Motor 1. Motor Connector disconnected.
2. Motor defective.
3. Paper Height Sensor Connector disconnected.
4. Paper Height Sensor defective.
5. Gear defective.
E7- 59 Finisher Upper Limit 1. Paper Upper Limit Sensor Connector disconnected.
2. Paper Upper Limit Sensor defective.
3. Paper Hold Sensor Connector disconnected.
4. Paper Hold Sensor defective.
E7- 90 Hardware Key Abnormal 1. Incorrect Hardware Key installed.
2. Hardware Key defective.
E13: Out of Toner
Code Function Possible Cause(s)
E13 No Toner Detection 1. Out of Toner.
2. Toner Bottle not installed.
3. Toner Bottle not installed correctly.
4. Toner Sensor disconnected.
5. Toner Sensor defective.
6. SPC PCB connector disconnected.
7. SPC PCB defective.
LCD Message Possible Cause(s)
HDD Option Requires
Additional Sort Memory
Minimum 16 MB
1. Additional Sort memory is not installed.
• DA-SM16 (16 MB)
• DA-SM64 (64 MB)
• DA-SM28 (128 MB)
2. Make sure the SDRM PC Board was installed properly.
E7: Optional Unit Error (DA-FS300)
Code Function Possible Cause(s)
