Panasonic DP-2330

155
DP-2330/3030
MAR 2005
Ver. 2.1
DP-2310/3010
E4- 10 Fuser Fan Motor Rotation 1. Fuser Fan connector disconnected.
2. Fuser Fan defective.
3. SPC PCB connector disconnected.
4. SPC PCB defective.
5. LVPS defective.
E5: System Error
Code Function Possible Cause(s)
E5- 05 Vp (+24V, Scanner) 1. SDR PCB connector disconnected.
2. SDR PCB defective.
3. SPC PCB connector disconnected.
4. SPC PCB defective.
5. LVPS defective.
E5- 11 Printer Engine Communication
Abnormal
1. SPC PCB connector disconnected.
2. SPC PCB defective.
3. SC PCB connector disconnected.
4. SC PCB defective.
E5- 12 Scanner Engine
Communication Abnormal
E5- 17 Scanner Synchronization
E5- 19 Scanner Line Synchronization
E5- 42 Total Counter Connection 1. Total Counter connector disconnected.
2. Total Counter defective.
3. SPC PCB connector disconnected.
4. SPC PCB defective.
E5- 60 Power Supply Cooling Fan
Motor Rotation
1. Cooling Fan connector disconnected.
2. Cooling Fan defective.
3. SPC PCB connector disconnected.
4. SPC PCB defective.
5. LVPS defective.
E7: Optional Unit Error (DA-FS300)
Code Function Possible Cause(s)
E7- 22 Finisher Damper Motor 1. Motor Connector disconnected.
2. Motor defective.
3. Home Position Sensor Connector disconnected.
4. Home Position Sensor defective.
5. Gear defective.
E7- 23 Finisher Staple Motor 1. Motor Connector disconnected.
2. Motor defective.
3. Home Position Sensor Connector disconnected.
4. Home Position Sensor defective.
5. Micro Switch Harness disconnected.
6. Micro Switch defective.
7. Solenoid Harness disconnected.
8. Solenoid defective.
9. Gear defective.
10. Motor wedged with a jammed Staple.
E4: Fuser Unit Error
Code Function Possible Cause(s)
