146
DP-2330/3030
MAR 2005
Ver.2.1
DP-2310/3010
4.6.2. Jam Error Codes (J Code)
• J Code Log View Mode
The 5 most recent J Codes can be displayed on the Panel Display by pressing "Function" and "3" keys in
Standby mode.
Note:
If the machine is jammed, follow the procedure below.
1. Turn the Power Switch on the Left Side and the Main Power Switch on the Back of the machine to
the OFF position. (If Hard Disk Drive Unit is installed, refer to 3.7.7.)
2. Remove the Jammed paper.
3. Turn the Main Power Switch on the Back and the Power Switch on the Left Side of the machine to
the ON position.
4. Press the "Function" and "3" keys.
Section Jam Location
A Finisher
B Paper Transport Area
C Paper entry area
D2 2nd Paper Feed Unit
D3 3rd Paper Feed Unit
D4 4th Paper Feed Unit
E ADF/i-ADF
A
B
E
D2
D3
D4
To Next Page
