5.2. Service Modes (For Facsimile)
Caution:
The factory default parameters are preset (country dependent) for optimum performance and in
compliance with the local telecommunication regulations/standards, and do not need to be changed.
Changing some of these parameters may cause the unit to be no longer compliant or become
inoperable.
5.2.1. Fax Service Mode Procedure
1. To select the Service Mode
The Service Mode is selected when "FUNCTION", "ORIGINAL SIZE (LEDGER/A3)" and "3" keys on
the keypad are simultaneously pressed, then F1 will appear in the display.
Press "9" and "START" keys to enter F9 Mode: Unit Maintenance.
Select "00 FAX Service Mode" on the Touch Panel display to enter Facsimile Service Mode.
2. To exit the Service Mode
The Service Mode is reset when the "FUNCTION" and "C (CLEAR)" keys are pressed simultaneously.
5.2.2. FAX Service Mode Table
The following service modes are provided to assist you in setting operational functions of the unit and
determining the condition of the unit.
No. Service Mode Description
00 Not Used
01 Function Parameter Setting Allows changes to the function parameters (the home
position, etc.).
02 RAM Edit Mode Factory use only.
03 Print Parameter List / Report Prints the Function Parameter List, Page Memory Test, Printer
Report, All Document File, Protocol Trace and Toner Order
Form.
04 Modem Tests Generates various binary, tonal and DTMF signals, by the
modem.
05 Not Used
06 RAM Initialize Initialize RAM and restore the default value of the function
parameters.
Note: Turn the Power Switch to the OFF and back to the ON
position to enable the parameter settings.
07 Not Used
08 Check & Call Allows input of information for Service Alert Report,
Maintenance Alert Report and Toner Order Form.
09 System Maintenance Used for Firmware Update, Firmware Backup, Parameter
Restore, Parameter Backup, Transferring Firmware from the
PC to the Flash Card and Sending a Received File during a
fatal printer error.
