Panasonic DP-2330

36
DP-2330/3030
MAR 2005
Ver.2.1
DP-2310/3010
1.7. Fans and Motors
1.8. Clutches and Switches
Scanning Motor (201)
LVPS Fan (322)
LSU Fan (315)
Main Motor (907)
ADF Motor (1801)
Transport Motor (1320)
Toner Motor (958)
Lift DC Motor (1152)
Fan (459)
ILS PCB (19124)
(Front Cover Sensor)
Paper Feed Roller
Clutch (1105)
Paper Feed Roller
Clutch (1105)
Intermediate Roller
Clutch (957)
Sheet Bypass Feed
Roller Clutch (1105)
Registration Roller
Clutch (957)
ADF Roller
Clutch (1788)
Intermediate
Clutch (969)
Feed 2 Roller
Clutch (1787)
Micro Switch (461)
