Panasonic DP-2330

153
DP-2330/3030
MAR 2005
Ver. 2.1
DP-2310/3010
E2: Lift DC Motor Error
Code Function Possible Cause(s)
E2- 01 Lift Motor Rotation
(1st Paper Tray)
1. Level Sensor connector disconnected.
2. Level Sensor defective.
3. Lift Mechanism defective.
4. Lift Motor connector disconnected.
5. Lift Motor defective.
6. SPC PCB connector disconnected.
7. SPC PCB defective.
8. LVPS defective.
E2- 02
Lift Motor Rotation
(2nd Paper Tray)
1. Level Sensor connector disconnected.
2. Level Sensor defective.
3. Lift Mechanism defective.
4. Lift Motor connector disconnected.
5. Lift Motor defective.
6. SPC PCB connector disconnected.
7. SPC PCB defective.
8. CST2 PCB connector disconnected.
9. CST2 PCB defective.
10. LVPS defective.
E2- 03
E2- 04
Lift Motor Rotation
(3rd Paper Tray)
Lift Motor Rotation
(4th Paper Tray)
1. Level Sensor connector disconnected.
2. Level Sensor defective.
3. Lift Mechanism defective.
4. Lift Motor connector disconnected.
5. Lift Motor defective.
6. SPC PCB connector disconnected.
7. SPC PCB defective.
8. CST2 PCB connector disconnected.
9. CST2 PCB defective.
10. CST3 PCB connector disconnected.
11. CST3 PCB defective.
12. LVPS defective.
E2- 08 Sheet Bypass Initialization 1. Sensor connector disconnected.
2. Sensor defective.
3. SPC PCB connector disconnected.
4. SPC PCB defective.
5. LVPS defective.
E2- 10 System Console Drive Motor
Rotation
1. Drive Mechanism defective.
2. Drive Motor connector disconnected.
3. Drive Motor defective.
4. CST2 PCB connector disconnected.
5. CST3 PCB connector disconnected.
6. CST3 PCB defective.
7. LVPS connector disconnected.
8. LVPS defective.
9. SPC PCB connector disconnected.
10. SPC PCB defective.
