Panasonic DP-2330

233
DP-2330/3030
MAR 2005
Ver. 2.1
DP-2310/3010
6 System Description
6.1. Printing Process
Exit
Paper Feed
Toner
Discharge Lamp:
Transfer / Separation Fusing: Cleaning:
Primary Charge: Image Exposure: Developing:
Drum Surface
Approximately-750V DC
Charge Roller
Drum
Latent
Charge
Illumination
Magnetic
Doctor Blade
Gap = 0.6~
0.7 mm
Roller
Bias: -550 V
Latent Charge
Discharge
Lamp (LED)
Heat Roller
Fuser Lamp
Paper
Pressure
Roller
Latent Image
Bias
Transfer
Roller
Cleaning
Blade
OPC
Drum
Toner
Paper
Photo Electric
Conversion
(+DC)
(GND)
Aluminum
Layer
Developer
Transfer
Separation
Cleaning
Discharge
Lamp (LED)
Charger
Laser Exposure
Fusing
OPC
Drum
ADU
(-DC)
Magnetic
Roller
Discharge
Plate
OPC
Drum
Transfer
Charge
(+DC)
