Panasonic DP-2330

201
DP-2330/3030
MAR 2005
Ver. 2.1
DP-2310/3010
5.1.8. F9 Mode: Unit Maintenance
Set the machine to Service Mode and press "9" key on the Keypad.
↓
Press the "START" key.
↓
Select the desired code number on the Touch Panel display.
↓
If you wish to select another code number, scroll the menu with the arrow buttons.
↓
Select the desired function on the Touch Panel display and touch the "OK" button.
↓
When the "C (CLEAR)" key is touched, the selected code input will not be accepted.
↓
Press "FUNCTION" and "C (CLEAR)" keys simultaneously to exit the service mode.
F9 Mode
Service
Mode
Item Remarks
F9 Unit
Maintenance
00 Fax Service Mode
01 Service Alert Tel # Displays the contact number when a
machine malfunction occurs.
02 Firmware
Version
00 SC Displays the firmware version for SC.
01 SC Boot Displays the firmware version for SC
Boot.
02 PNL Displays the firmware version for PNL.
03 SPC Displays the firmware version for SPC.
04 Finisher Displays the firmware version for
finisher.
05 FAX Modem Displays the firmware version for FAX
option 1.
06 Not Used
07 SC2 Displays the firmware version for Slot 1.
03 Print
Device Info.
00 F5/F6 Parameters Prints the memory contents of the F5
and F6 modes.
01 Machine Information Prints the machine setup information list.
02 System Address
Info.
Prints the system memory setting.
03 RAM Address
Information
Prints the RAM data dump list.
04 RAM Edit
Mode
00 Relative Address Setting of Relative address.
01 Real Address Setting of Real address.
05 Not Used
