Panasonic DP-2330

255
DP-2330/3030
MAR 2005
Ver. 2.1
DP-2310/3010
GACLK- Gate Array Clock -
GND Ground
GOPSW1 Developer Missing Detection
HSYNC Horizontal Synchronous Signal
HUMSN Temp Humidity Sensor Signal
IICSCL IIC Transmission Clock
IICSDA IIC Transmission Signal
IOUTA Motor Control Signal
IOUTB Motor Control Signal
IPRXD Finisher IPC Reception
IPTXD Finisher IPC Transmission
KCDET Key Counter Option Detection
L+5V Laser Circuit +5 VDC Power Supply
L1 (R) Line Signal
L2 (T) Line Signal
LD Motor Lock Detection Signal
LD2WAY Photo Sensor DC Drive Voltage
LDBT Photo Sensor DC Drive Voltage
LDCST Photo Sensor DC Drive Voltage
LDCST2 Photo Sensor DC Drive Voltage
LDCST3 Photo Sensor DC Drive Voltage
LDCST4 Photo Sensor DC Drive Voltage
LDDOR Photo Sensor DC Drive Voltage
LDDUP1 Photo Sensor DC Drive Voltage
LDDUP2 Photo Sensor DC Drive Voltage
LDDUP3 Photo Sensor DC Drive Voltage
LDDUP4 Photo Sensor DC Drive Voltage
LDEN Laser Control
LDESEN Photo Sensor DC Drive Voltage
LDEX1 Photo Sensor DC Drive Voltage
LDEX2 Photo Sensor DC Drive Voltage
LDEX3 Photo Sensor DC Drive Voltage
LDEX4 Photo Sensor DC Drive Voltage
LDFPCHK2 Photo Sensor DC Drive Voltage
LDFPCHK3 Photo Sensor DC Drive Voltage
LDFPCHK4 Photo Sensor DC Drive Voltage
LDHTJ Photo Sensor DC Drive Voltage
LDI+ Laser Diode Control +
LDI- Laser Diode Control -
LDJAM2 Photo Sensor DC Drive Voltage
LDJAM3 Photo Sensor DC Drive Voltage
LDJAM4 Photo Sensor DC Drive Voltage
LDMF4 Photo Sensor DC Drive Voltage
LDMFP Photo Sensor DC Drive Voltage
LDMFR Photo Sensor DC Drive Voltage
LDPHK2 Photo Sensor DC Drive Voltage
LDPHK3 Photo Sensor DC Drive Voltage
Signal Name Function
